Name: Shure ULXD4D Dual Channel Digital Wireless Receiver 470-534 MHz
SKU: 232867

Product Details ＋

ULXD Series Specification Sheet

The Shure ULXD4D Dual Channel Digital Wireless Receiver offers two channels of umcompromising audio quality, RF signal stability and efficiency, and advanced setup features in a single ract unit. Rugged, yet lightweight and compact, the all-metal chassis houses two independent receivers, each with its own audio and RF meters, gain control, and receiver outputs that can be either direct or summed for flexible signal routing.
With RF cascade and two Ethernet ports, units easily can share RF signal and be networked together for simplified frequency coordination and deployment. For networked audio applications, Dante digital networking allows multiple channels of audio to be transmitted and received over a single Ethernet cable. When more compatible frequencies over shorter distances, High Density mode can be enabled to dramatically increase the number of available open frequencies.

ULXD4 Features:

Frequency Band: 470-534 MHz

Two receivers in a rugged 1RU metal chassis with internal power supply

Individual gain controls, LED meters, and XLR outputs for each channel

Up to 64 MHz tuning range (region dependent)

Digital predictive switching diversity

High Density mode optimizes ULX-D systems to simultaneously operate significantly more channels in applications up to 30 meters

RF cascade ports allow distribution of RF signal to another unit

Optimized scanning automatically finds, prioritizes, and deploys the cleanest frequencies to transmitters over IR sync

Bodypack frequency diversity ensures uninterrupted audio for mission-critical applications

AES 256-bit encryption-enabled for secure transmission

Audio summing routes both audio channels to each XLR receiver output
