The Blackhawk Wideband Omni Antenna provides an ideal solution for 3G / 4G voice and data applications. With the rollout of new 3G and 4G frequencies such as 700 MHz 4GX and 2600 MHz 4G traditional omni-directional antennas just haven’t been able to keep up. Blackhawk wideband omni-directional antennas provide high gain across the full cellular band 700 to 2700 MHz regardless of mounting direction allowing quick and easy installation with no technical know-how required.
The true wideband performance has been achieved through a clever engineering design utilising multi-sized collinear radiators and microwave-grade combiners demonstrating consistently high gain with exceptional azimuthal stability.
FEATURES
- 6 dBi gain across lower bands 698-960 MHz
- 6 dBi gain across upper bands 1710-2700 MHz
- Ruggedised construction for Australian conditions
- UV-stable PVC construction
- Stainless steel L-bracket included
- Integrated N Female connector
- Optional 6m or 10m LMR240 cable
| Input Connector | N Female |
| Cable (optional) | 6m PT240 LSHF SMA Male
10m PT240 LSHF SMA Male |
| Lightning Protection | DC Ground |
| Radiator Material | Collinear copper elements |
| Radome Material | UV stable PVC |
| Mounting | Stainless Steel pole mount Ø30-50 mm |
| Dimensions | Ø63 × 680 mm |
| Weight | 1.9 kg |
| Packing Dimensions | 700 × 100 × 100 mm |
| Rated Wind Velocity | 210 km/h |
| Operating Temperature | -40 to 65°C |
